Mean Well ELG-300-12A

Article number:
ELG-300-12A
Article GTIN:
4711287443362

Request a sample

Ask a product question

Downloads

AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC; Output 12Vdc at 22A; IP67; Io and Vo adjus

Properties

  • Series: ELG-300
  • Brand: Mean Well
  • Dimensions LxWxH (mm): 246x77x39.5 mm
  • Warranty: 60 Months Bring-in
  • Gross weight: 1450
  • Type: AC-DC
  • Form factor: Enclosed
  • Mounting method: Chasis mount
  • Min. output voltages (V): 12
  • Max. output voltage (V): 12
  • Number of output voltages: 1
  • Max output power (W): 264
  • Input voltage (V): 100 - 305
  • Min. input voltage: 100
  • Max. input voltage (V): 305
  • Max. output current (A): 22
  • Number of output currents: 1
  • IP rating: IP65
  • LED driver: Yes
  • Dimming technologies: Analog, Potentiometer
  • Control signals: No control signal
