Mean Well HLG-100H-20AB

Article number:
HLG-100H-20AB
Article GTIN:
4711287481784

Request a sample

Ask a product question

Downloads

AC-DC Single output LED Driver Mix Mode (CV+CC) with PFC; Output 20Vdc at 4.8A; IP65; Dimming with 1

Properties

  • Series: HLG-100H
  • Brand: Mean Well
  • Dimensions LxWxH (mm): 220x68x38.8 mm
  • Warranty: 84 Months Bring-In
  • Gross weight: 1120
  • Type: AC-DC
  • Form factor: Enclosed
  • Mounting method: Chasis mount
  • Min. output voltages (V): 20
  • Max. output voltage (V): 20
  • Number of output voltages: 1
  • Max output power (W): 96
  • Input voltage (V): 90 - 305
  • Min. input voltage: 90
  • Max. input voltage (V): 305
  • Max. output current (A): 4.8
  • Number of output currents: 1
  • IP rating: IP65
  • LED driver: Yes
  • Dimming technologies: 1-10V, PWM, Resistance
  • Control signals: No control signal
