Mean Well HLG-320H-36B

Article number:
HLG-320H-36B
Article GTIN:
4711287451046

Request a sample

Ask a product question

Downloads

AC-DC Single output LED Driver Mix Mode (CV+CC) with built-in PFC; Output 36Vdc at 8.9A; IP67; Cable output; Dimming with 1-10V PWM resistance

Properties

  • Series: HLG-320H
  • Brand: Mean Well
  • Dimensions LxWxH (mm): 338x132x60 mm
  • Warranty: 84 Months Bring-In
  • Gross weight: 1880
  • Type: AC-DC
  • Form factor: Enclosed
  • Mounting method: Chasis mount
  • Min. output voltages (V): 36
  • Max. output voltage (V): 36
  • Number of output voltages: 1
  • Max output power (W): 320
  • Input voltage (V): 90 - 305
  • Min. input voltage: 90
  • Max. input voltage (V): 305
  • Max. output current (A): 9
  • Number of output currents: 1
  • IP rating: IP67
  • LED driver: Yes
  • Dimming technologies: 1-10V, PWM, Resistance
  • Control signals: No control signals
  • Carbon footprint (kgCO2e/pcs): 19.21
