Mean Well LPF-16-12
Article number:
LPF-16-12
Article GTIN:
4711287439785
Downloads
AC-DC Single output LED driver Mix Mode (CV+CC); Output 12Vdc at 1.34A; cable output
Properties
- Series: LPF-16
- Brand: Mean Well
- Dimensions LxWxH (mm): 148x40x32 mm
- Warranty: 60 Months Bring-In
- Gross weight: 240
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 6.6
- Max. output voltage (V): 12
- Number of output voltages: 1
- Max output power (W): 16
- Input voltage (V): 90 - 305
- Min. input voltage: 90
- Max. input voltage (V): 305
- Max. output current (A): 1.34
- Number of output currents: 1
- IP rating: IP30
- LED driver: Yes
- Dimming technologies: No Dimming
- Control signals: No control signal
