Mean Well LPF-60D-12

Article number:
LPF-60D-12
Article GTIN:
4711287458885

Request a sample

Ask a product question

Downloads

AC-DC Single output LED driver Mix Mode (CV+CC); Output 12Vdc at 5A; cable output; Dimming with 1-10

Properties

  • Series: LPF-60D
  • Brand: Mean Well
  • Dimensions LxWxH (mm): 162.5x43x32 mm
  • Warranty: 60 Months Bring-In
  • Gross weight: 460
  • Type: AC-DC
  • Form factor: Enclosed
  • Mounting method: Chasis mount
  • Min. output voltages (V): 7.2
  • Max. output voltage (V): 12
  • Number of output voltages: 1
  • Max output power (W): 60
  • Input voltage (V): 90 - 305
  • Min. input voltage: 90
  • Max. input voltage (V): 305
  • Max. output current (A): 5
  • Number of output currents: 1
  • IP rating: IP67
  • LED driver: Yes
  • Dimming technologies: 1-10V, PWM, Resistance
  • Control signals: No control signal
