Mean Well XLC-25-H-BS
Article number:
XLC-25-H-BS
Article GTIN:
4711287487328
Downloads
AC-DC constant power LED driver, class II with PFC; output current selectable with DIP-switch
Properties
- Series: XLC-25
- Brand: Mean Well
- Dimensions LxWxH (mm): 147x40x32 mm
- Warranty: 60 Months Bring-In
- Gross weight: 160
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 9
- Max. output voltage (V): 54
- Number of output voltages: 1
- Max output power (W): 25
- Input voltage (V): 100 - 305
- Min. input voltage: 100
- Max. input voltage (V): 305
- Max. output current (A): 1.05
- Number of output currents: 1
- IP rating: No IP assigned
- LED driver: Yes
- Dimming technologies: 0-10V, PWM, Resistance
- Control signals: No control signal
