Mean Well XLG-150-H-AB
Article number:
XLG-150-H-AB
Article GTIN:
4711287457055
Downloads
AC-DC Single output LED driver Constant Power Mode with built-in PFC; Output 56Vdc at 4.17A
Properties
- Series: XLG-150
- Brand: Mean Well
- Dimensions LxWxH (mm): 180x63x35.5 mm
- Warranty: 60 Months Bring-In
- Gross weight: 800
- Type: AC-DC
- Form factor: Enclosed
- Mounting method: Chasis mount
- Min. output voltages (V): 27
- Max. output voltage (V): 56
- Number of output voltages: 1
- Max output power (W): 150
- Input voltage (V): 100 - 305
- Min. input voltage: 100
- Max. input voltage (V): 305
- Max. output current (A): 4.17
- Number of output currents: 1
- IP rating: IP67
- LED driver: Yes
- Dimming technologies: 0-10V, PWM, Resistance
- Control signals: No control signal
